99,00 €

Zaloga : 0

POLICETECH IPC-B4300-Z IP VIDEO SURVEILLANCE CAMERA

4Mp (2560x1440) / Motorized lens 97°-31° / Min. Illumination: 0,05 LUX / IR LED range up to 40m / Power Consumption max. 1.8W

  • 4 Megapixel
  • Domet IR do 40m
  • Nastavljiva leča 2.8-12mm
  • Motorizerana leča
  • Napajanje preko Etherneta
  • Interni spomin

:

Camera
Image Sensor: 1/3” 4Megapixel progresive CMOS
Effective Pixels: 2560(H)x1440(V)
RAM/ROM: 256MB/16MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s
Minimum Illumination: 0.05Lux/F1.8( Color,1/3s,30IRE)
0.3Lux/F1.8( Color,1/30s,30IRE)
0Lux/F1.8(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 40m(131ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 2

Lens
Lens Type: Motorized
Mount Type: Board-in
Focal Length:     2.8mm~12mm
Max. Aperture: F1.8
Angle of View: H:97°~31°, V:54°~17°
Focus Control: Fixed
Close Focus Distance: 0.2m

PTZ
Pan/Tilt Range : Pan:0° ~360°; Tilt:0° ~90°; Rotation:0° ~360°

Intelligence
Event Trigger: Motion detection, Video tampering, Network disconnection, Scene change, IP address conflict, Illegal Access,Storage anomaly

Video
Compression: H.265/H.264/H.264B/MJPEG(Sub Stream)
Smart Codec: Support H.265+/H.264+
Streaming Capability: 2 Streams
Resolution: 4M(2560x1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate: Main Stream: 4M(1 ~ 20fps), Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control: CBR/VBR
Bit Rate: H.264: 32K~6144K, H.265: 12K~ 6144K
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / DWDR
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detetion: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization (EIS): N/A
Smart IR: Support
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)

Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP; NTP;Bonjour;Multicast;ICMP;IGMP;TLS;SSH
Interoperability: ONVIF Profile S&G, API
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users/20 Users
Edge Storage:     NAS(Network Attached Storage), Local PC for instant recording, Micro SD Card 128GB
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart PSS, DSS,DMSS
Smart Phone: IOS, Android

Certifications
Certifications: CE: (EN 60950:2000), FCC: FCC Part 15 Subpart B

Electrical
Power Supply: DC12V, PoE (802.3af)(Class 0)
Power Consumption:     DC12V: 1.8W, 5.3W(IR On)
PoE: 2.2W, 6.3W(IR On)

Environmental
Operating Conditions: -30° C ~ +60° C / Less than 95% RH
Strorage Conditions: -30° C ~ +60° C / Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: N/A

Construction
Casing: Metal+Plastic
Dimensions: 243.6mm×90.7mm×90.2mm
Net Weight: 0.434Kg
Gross Weight: 0.693Kg



Camera
Image Sensor: 1/3” 4Megapixel progresive CMOS
Effective Pixels: 2560(H)x1440(V)
RAM/ROM: 256MB/16MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s
Minimum Illumination: 0.05Lux/F1.8( Color,1/3s,30IRE)
0.3Lux/F1.8( Color,1/30s,30IRE)
0Lux/F1.8(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 40m(131ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 2

Lens
Lens Type: Motorized
Mount Type: Board-in
Focal Length:     2.8mm~12mm
Max. Aperture: F1.8
Angle of View: H:97°~31°, V:54°~17°
Focus Control: Fixed
Close Focus Distance: 0.2m

PTZ
Pan/Tilt Range : Pan:0° ~360°; Tilt:0° ~90°; Rotation:0° ~360°

Intelligence
Event Trigger: Motion detection, Video tampering, Network disconnection, Scene change, IP address conflict, Illegal Access,Storage anomaly

Video
Compression: H.265/H.264/H.264B/MJPEG(Sub Stream)
Smart Codec: Support H.265+/H.264+
Streaming Capability: 2 Streams
Resolution: 4M(2560x1440)/3M(2304×1296)/1080P(1920×1080)/720P(1280×720)/VGA(640×480)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate: Main Stream: 4M(1 ~ 20fps), Sub Stream: D1(1 ~ 25/30fps)
Bit Rate Control: CBR/VBR
Bit Rate: H.264: 32K~6144K, H.265: 12K~ 6144K
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / DWDR
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detetion: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization (EIS): N/A
Smart IR: Support
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)

Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;FTP;DHCP;DNS;DDNS;IPV4/V6;QoS;UPnP; NTP;Bonjour;Multicast;ICMP;IGMP;TLS;SSH
Interoperability: ONVIF Profile S&G, API
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users/20 Users
Edge Storage:     NAS(Network Attached Storage), Local PC for instant recording, Micro SD Card 128GB
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart PSS, DSS,DMSS
Smart Phone: IOS, Android

Certifications
Certifications: CE: (EN 60950:2000), FCC: FCC Part 15 Subpart B

Electrical
Power Supply: DC12V, PoE (802.3af)(Class 0)
Power Consumption:     DC12V: 1.8W, 5.3W(IR On)
PoE: 2.2W, 6.3W(IR On)

Environmental
Operating Conditions: -30° C ~ +60° C / Less than 95% RH
Strorage Conditions: -30° C ~ +60° C / Less than 95% RH
Ingress Protection: IP67
Vandal Resistance: N/A

Construction
Casing: Metal+Plastic
Dimensions: 243.6mm×90.7mm×90.2mm
Net Weight: 0.434Kg
Gross Weight: 0.693Kg
