-25,00%

195,00 €

146,25 €

Zaloga : 50+

POLICETECH IPC-B5341T-Z IP VIDEO SURVEILLANCE CAMERA

5Mp (2592×1944) / Motorized lens 133°~ 33° / Min. Illumination: 0.005 LUX / IR LED range up to 60m / Power consumption Max. 9.8W / IVA (Tripwire, intrusion)

  • 5 Megapixel
  • Motorizerana leča
  • Napajanje preko Etherneta
  • Interni spomin
  • Alarm izhod

Camera
Image Sensor: 1/2.7”5Megapixel progressive CMOS
Effective Pixels:  2592 (H) ×1944 (V)
ROM: 128 MB
RAM: 512 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100000 s
Min. Illumination: 0.005 Lux@F1.5
IR Distance: 60 m
IR On/Off Control: Auto/Manual
IR LEDs Number: 4 (IR LEDs)
Pan/Tilt/Rotation Range: Horizontal: 0°–360°; vertical: 0°–90°; rotation: 0°–360°

Lens
Lens Type: Motorized vari-focal
Mount Type: φ14
Focal Length: 2.7 mm–13.5 mm
Max. Aperture:     F1.5
Field of View: Horizontal: 99°–26°
Vertical: 72° –20°
Diagonal: 133° –33°
Iris Type: Fixed aperture
Close Focus Distance: 0.8 m

Professional, Intelligent
Perimeter Protection: Tripwire; intrusion (Recognition of human and vehicle)
Intelligent Search:Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG
Smart Codec:Yes
Video Frame Rate: Main stream (2592 × 1944@1–20 fps) (2688 × 1520@1–25/30 fps) sub stream(704 × 576@1–25 fps/704 × 480@1–30 fps) third stream(1280 × 720@1–25/30 fps)
Stream Capability: 3 streams
Resolution: 5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control: CBR/VBR
Video Bit Rate:     H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps
Day/Night: Auto(ICR)/Color/B/W
BLC: Yes
HLC: Yes
WDR:     120 dB
White Balance:     Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detection: OFF/ON (4 areas, rectangular)
Region of Interest(RoI): Yes (4 areas)
Smart IR: Yes
Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution.)
Mirror:     Yes
Privacy Masking:4 areas

Audio
Audio Compression: G.711a; G.711Mu; G726; AAC

Network
Network: RJ-45 (10/100 Base-T)
Protocol: IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;
RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
Interoperability: ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec
Scene Self-adaptation:     Yes
User/Host: 20 (Total bandwidth: 64 M)
Edge Storage: FTP; SFTP; Micro SD Card (support max. 256 G); Cloud; NAS
Browser: IE: IE8, IE9, IE11, Chrome, Firefox
Management Software: Smart PSS, DSS, DMSS
Mobile Phone: IOS; Android

Certification
Certifications: CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port
Audio Input: 1-channel (RCA port)
Audio Output: 1-channel (RCA port)
Alarm Input: 1 channel in: 5mA 3V–5V DC
Alarm Output: 1 channel out: 300mA 12V DC
Power
Power Supply: 12V DC/PoE (802.3af)
Power Consumption: < 9.8W

Environment
Operating Conditions: -30°C to +60°C /less than≤95%
Strorage Conditions: -40°C to +60°C
Ingress Protection: IP67

Structure
Casing:     Metal
Dimensions: 244.1 mm × 79.0 mm × 75.9 mm (L × W × H)
Net Weight: 820 g
Gross Weight: 1090 g
