Camera
Image Sensor: 1/2.7”5Megapixel progressive CMOS
Max. Resolution: 2592 (H) ×1944 (V)
ROM: 128 MB
RAM: 512 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100000 s
Min. Illumination: 0.005 Lux@F1.6
S/N Ratio: > 56 dB
Illumination Distance: 50 m
Illuminator On/Off Control: Auto/Manual
Illuminator Number: 2 (IR LED)
Pan/Tilt/Rotation Range: Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360°

Lens
Lens Type: Fixed-focal
Mount Type: M12
Focal Length: 2.8 mm
Max. Aperture: F1.6
Field of View: 2.8 mm: Horizontal:98°; vertical: 72°; diagonal: 130°
Iris Type: Fixed
Close Focus Distance: 0.9 m

Professional, Intelligent
Perimeter Protection: Tripwire; intrusion (Recognition of human and vehicle)
Intelligent Search: Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG(only supported by sub stream)
Smart Codec: Smart H.265+/ Smart H.264+
Video Frame Rate: Main stream (2592 × 1944@1–20 fps), (2688 × 1520@1–25/30 fps); sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps); third stream (1280 × 720@1–25/30 fps)
Stream Capability: 3 streams
Resolution: 5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control: CBR/VBR
Video Bit Rate: H.264: 3 Kbps–8192 Kbps; H.265: 3 Kbps–8192 Kbps
Day/Night: Auto(ICR)/Color/B/W
BLC: Yes
HLC: Yes
WDR: 120 dB
White Balance: Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detection: OFF/ON (4 areas, rectangular)
Region of Interest(RoI): Yes (4 areas)
Smart Illumination: Yes
Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)
Mirror: Yes
Privacy Masking: 4 areas

Audio
Built-in MIC: Yes
Audio Compression: G.711a; G.711Mu; G726; AAC

Alarm
Alarm Event: No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; intensity change; tripwire; intrusion; SMD

Network
Network: RJ-45 (10/100 Base-T)
SDK and API: Yes
Protocol: IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP
Interoperability: ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec
Scene Self-adaptation: Yes
User/Host: 20 (Total bandwidth: 64M)
Storage    : FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS
Browser: IE: IE8, IE9, IE11, Chrome, Firefox
Management Software: Smart PSS, DSS, DMSS
Mobile Phone: IOS; Android

Certification
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Power
Power Supply: 12V DC/PoE (802.3af)
Power Consumption: <8.1W

Environment
Operating Conditions: -40°C to +60°C /less than 95%
Storage Conditions: -40°C to +60°C
Protection Grade: IP67

Structure
Casing Inner core: Metal
Cover: Metal
Decoration ring: Plastic
Dimensions: 99.1 mm × Φ121.9 mm
Net Weight: 480 g
Gross Weight: 660 g
