> 8-MP 1/2.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light and IR LED; the max. IR illumination distance is 50 m and warm light distance is 40 m. · ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built-in dual Mic; built-in speaker; support two-way talk.
> 12 VDC/PoE power supply.
> IP67 protection.
> Sound and light alarm (red and blue lights).
> SMD 4.0.
> One-tap arming/disarming through alarm input.

Camera
Image Sensor: 1/2.8" CMOS
Max. Resolution: 3840 (H) × 2160 (V)
ROM: 128 MB
RAM: 1 GB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Min. Illumination: 0.004 lux@F1.0 (Color, 30 IRE); 0.0004 lux@F1.0 (B/W, 30 IRE); 0 lux (illuminator on)
S/N Ratio: >56 dB
Illumination Distance: Up to 50 m (IR); Up to 40 m (warm light)
Illuminator On/Off Control: Auto/Manual
Illuminator Number: 2 (IR LED); 2 (warm light)
Angle Adjustment: Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°

Lens
Lens Type: Motorized vari-focal
Mount Type: φ16
Focal Length: 2.7 mm–13.5 mm
Max. Aperture: F1.0
Field of View: Horizontal: 108°–34°
Vertical:56°–19°
Diagonal:130°–39°
Iris Type: Fixed
Close Focus Distance: 1.5 m

DORI Distance:
W: Detect: 89.9 m; Observe: 36.0 m; Recognize: 18.0 m; Identify: 9.0 m
T: Detect: 257.4 m; Observe: 103.0 m; Recognize: 51.5 m; Identify: 25.7 m

Professional, intelligent
IVS (Perimeter Protection): Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
SMD 4.0: Less false alarm, longer detection distance
Quick Pick: With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events
Smart Search: Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
AI SSA: Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions.

Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec: Smart H.265+; Smart H.264+
AI Coding: AI H.265; AI H.264
Video Frame Rate: Main stream: 3840 × 2160@ (1–30 fps); Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps); Third stream: 1920 × 1080@ (1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
Stream Capability: 3 streams
Resolution: 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control: CBR/VBR
Video Bit Rate: H.264: 3 kbps–8192 kbps; H.265: 3 kbps–8192 kbps
Day/Night: Auto (ICR)/Color/B/W
BLC: Yes
HLC: Yes
WDR: 120 dB
Scene Self-adaptation: Yes
White Balance:    Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control: Auto; manual
Noise Reduction: 3D NR
Motion Detection: OFF/ON (4 areas)
Region of Interest (RoI): Yes (4 areas)
Image Stabilization: Electronic Image Stabilization (EIS)
Smart Illumination: Yes
Defog: Yes
Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror:    Yes
Privacy Masking: 4 areas

Audio
Built-in Mic: Yes, built-in dual Mic
Built-in speaker: Yes, built-in speaker
Audio Compression: Audio Compression PCM; G.711a; G.711Mu; G.726; G.723

Alarm
Alarm Event: No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; security exception

Network
Network: RJ-45 (10/100 Base-T)
SDK and API: Yes
Cyber Security: Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Interoperability: ONVIF (Profile S; Profile G; Profile T); CGI
User/Host: 20 (Total bandwidth: 72 M)
Storage: FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser: IE: IE8/9/11, Chrome, Firefox
Management Software: SmartPSS Lite; DSS; DMSS
Mobile Phone: iOS; Android

Certification
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14

Port
Audio Input: 1 channel (RCA port)
Audio Output: 1 channel (RCA port)
Alarm Input: 1 channel in: wet contact, 5 mA 3 V–5 VDC
Alarm Output: 1 channel out: wet contact, 300 mA 12 VDC

Power
Power Supply: 12V DC/PoE (802.3af)
Power Consumption: Basic: 4.3 W (12 VDC); 5.5 W (PoE)
Max. (H.265+main stream/IR intensity+warm light on): 7.9 W (12 VDC); 9.8 W (PoE)

Environment
Operating Conditions: –30 °C to +60 °C / Less than 95% RH
Storage Conditions: –40 °C to +60 °C
Protection Grade: IP67

Structure
Casing: Metal + plastic
Dimensions: 288.4 mm × 94.4 mm × 84.7 mm (L × W × H)
Net Weight: 1.05 kg
Gross Weight: 1.35 kg
