> 4-MP 1/3" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2560 × 1440)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED and warm light, and the max. IR distance is 30 m, the max. warm light distance is 30 m.
> WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Abnormality detection: Motion detection, video tampering, audio detection, network disconnection, IP conflict and illegal access.
> Built in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 and IK08 protection.
> Supports human detection.

Camera
– Image Sensor: 1/3" CMOS
– Max. Resolution: 2560 (H) × 1440 (V)
– ROM: 128 MB
– RAM: 128 MB
– Scanning System: Progressive
– Electronic Shutter Speed: Auto/Manual, 1/3 s–1/100,000 s
– Min. Illumination: 0.008 lux @ F1.6 (Color, 30 IRE); 0.0008 lux @ F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
– S/N Ratio: >56 dB
– Illumination Distance: Up to 30 m (IR); up to 30 m (Warm light)
– Illuminator On/Off Control: Auto/Manual
– Illuminator Number: 3 × IR LED; 4 × Warm light
– Angle Adjustment: Pan: 0°–355°; Tilt: 0°–65°; Rotation: 0°–355°

Lens
– Lens Type: Fixed-focal
– Lens Mount: M12
– Focal Length: 2.8 mm
– Max. Aperture: F1.6
– Field of View: H: 95.5°; V: 53.4°; D: 110.7°
– Iris Control: Fixed
– Close Focus Distance: 2.8 mm: 1.0 m

DORI Distance
Detect: 61.6 m; Observe: 24.6 m; Recognize: 12.3 m; Identify: 6.2 m
*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The values listed do not reflect intelligent function distances. For intelligent function distances, refer to the installation and commissioning manual or project design tool.

Intelligence
– Human Detection: Supports classification and accurate detection of humans
– Smart Search: Works together with Smart NVR to perform refined intelligent search, event extraction and event video merging

Video
– Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
– Smart Codec: Smart H.265+; Smart H.264+
– Video Frame Rate: Main stream: 2560 × 1440 @ 1–25/30 fps; Sub stream: 704 × 576 @ 1–25 fps / 704 × 480 @ 1–30 fps
– Streaming Capability: 2 streams
– Resolution: 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576 / 704 × 480); VGA (640 × 480); CIF (352 × 288 / 352 × 240)
– Bit Rate Control: VBR; CBR
– Video Bit Rate: H.264: 32 kbps–4096 kbps; H.265: 12 kbps–4096 kbps
– Day/Night: Auto (ICR) / Color / B/W
– BLC: Yes
– HLC: Yes
– WDR: 120 dB
– White Balance: Auto; Natural; Street Lamp; Outdoor; Manual; Regional Custom
– Gain Control: Auto/Manual
– Noise Reduction: 3D NR
– Motion Detection: Off/On, 4 rectangular areas
– Region of Interest (RoI): Yes, 4 areas
– Smart Illumination: Yes
– Smart Dual Light: Yes
– Image Rotation: 0° / 180°
– Mirror: Yes
– Privacy Masking: 4 areas
*The values above are the maximum frame rates of each stream. For multiple streams, the values are subject to the total encoding capacity.

Audio
– Built-in MIC: Yes, built-in microphone
– Audio Compression: G.711a; G.711Mu; PCM; G.726

Alarm
– Alarm Event: Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception

Network
– Network Port: RJ-45 (10/100 Base-T)
– SDK and API: Yes
– Network Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P; Auto Registration
– Interoperability: ONVIF (Profile S & Profile T); CGI
– User/Host: 6 users, total bandwidth: 24 M
– Storage: FTP
– Browser: IE; Chrome; Firefox
– Management Software: Smart PSS Lite; DSS; DMSS
– Mobile Client: iOS; Android
– Security: Digest; WSSE; Account lockout; Security logs; Generation and importing of X.509 certification; HTTPS; Trusted boot; Trusted execution; Trusted upgrade

Certification
– Certifications: CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Power
– Power Supply: 12 VDC (±30%); PoE (802.3af)
– Power Consumption: Basic: 2.3 W (12 VDC); 3.1 W (PoE); Max.: 6.8 W (12 VDC); 7.9 W (PoE) with H.265, intelligence on, WDR and illuminator intensity

Environment
– Operating Temperature: –40 °C to +60 °C
– Operating Humidity: ≤95% RH, non-condensing
– Storage Temperature: –40 °C to +60 °C
– Storage Humidity: ≤95% RH, non-condensing
– Protection: IP67; IK08

Structure
– Casing Material: Metal + Plastic
– Product Dimensions: 81.0 mm × Φ109.9 mm
– Net Weight: 0.33 kg
– Gross Weight: 0.48 kg
