Camera
Image Sensor: 1/2.7" CMOS
Max. Resolution: 2880 (H) × 1620 (V)
ROM: 16 MB
RAM: 128 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Min. Illumination: 0.03 Lux@F2.0 (Color, 30 IRE), 0.003 Lux@F2.0 (B/W, 30 IRE), 0 Lux (Illuminator on)
S/N Ratio: > 56 dB
Illumination Distance: 30 m (IR)
Illuminator On/Off Control: Auto/Manual
Illuminator Number: 1 (IR LED)

Lens
Lens Type: Fixed-focal
Lens Mount: M12
Focal Length: 3.6 mm
Max. Aperture: F2.0
Field of View : Horizontal: 92°; Vertical: 48°; Diagonal: 109°
Iris Control: Fixed
Close Focus Distance: 1.3 m

DORI Distance
Detect: 76.0 m; Observe: 30.4 m, Recognize: 15.2 m, Identify: 7.6 m

Video
Video Compression: H.265; H.264; H.264B; MJPEG (only supported by the substream)
Smart Codec: Smart H.265+; Smart H.264+
Video Frame Rate:
Main stream: 2880 × 1620 (1 fps–20 fps), 2688 × 1520 (1 fps–25/30 fps); Sub stream:704 × 576 (1 fps–25 fps), 704 × 480 (1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability: 2 streams
Resolution: 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control: CBR/VBR
Video Bit Rate: H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps
Day/Night: Auto (ICR)/Color/B/W
BLC: Yes
HLC: Yes
WDR: DWDR
White Balance: Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control: Auto; manual
Noise Reduction: 3D NR
Motion Detection: OFF/ON (4 areas, rectangular)
Region of Interest (RoI): Yes (4 areas)
Smart Illumination: Yes
Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror: Yes
Privacy Masking: 4 areas

Audio
Built-in MIC: Yes
Audio Compression: G.711a; G.711Mu; G.726; PCM

Alarm
Alarm Event: Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception

Network
Network Port: RJ-45 (10/100 Base-T)
SDK and API: Yes
Cyber Security: Video encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
Network Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast
Interoperability: ONVIF (Profile S/Profile T); CGI; P2P; Genetec; Milestone
User/Host: 6 (Total bandwidth: 48 M)
Storage: FTP
Browser: IE, Chrome, Firefox
Management Software: Smart PSS; DSS; DMSS
Mobile Client: iOS; Android

Certifications
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B

Power
Power Supply: 12V DC/PoE (802.3af)
Power Consumption: Basic: 1.7 W (12V DC); 2.5W (PoE); Max. (ICR + H.265 + max. resolution + main stream + DWDR + IR intensity): 3.7 W (12V DC); 4.5 W (PoE)

Environment
Operating Temperature: -40 °C to +60 °C
Operating Humidity:  ≤ 95%
Storage Temperature: 40 °C to +60 °C
Protection: IP67

Structure
Casing: Metal
Product Dimensions: 85.6 mm × Φ94.0 mm
Net Weight: 0.32 kg
Gross Weight: 0.43 kg
