10.9w

Camera
Image Sensor: 1/1.8” 8Megapixel progressive CMOS
Effective Pixels: 3840(H) x2160(V)
RAM/ROM: 512MB/32MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual, 1/3~1/100000s
Minimum Illumination: 0.004Lux/F1.9( Color,1/3s,30IRE), 0.09Lux/F1.9 Color,1/30s,30IRE), 0Lux/F1.9(IR on)
S/N Ratio: More than 50dB
IR Distance: Distance up to 30m
IR On/Off Control: Auto/ Manual
IR LEDs: 4

Lens
Lens Type: Motorized
Mount Type: Board-in
Focal Length: 3.7mm~11mm
Max. Aperture: F1.9
Angle of View: H:112°~46°, V:60°~26°
Focus Control: Fiksen
Close Focus Distance: 0.2m

Intelligence
Event Trigger: Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly
IVS: Tripwire, Intrusion

Video
Compression:  H.265/H.264H/MJPEG(Sub Stream)
Smart Codec: Support H.265+/H.264+
Streaming Capability: 2 Streams
Resolution: 4K(3840×2160) / 6M(3072×2048) / 5M(2560×1920) / 3M(2048x1536) / 3M(2304×1296) / 1080P(1920×1080) / 1.3M(1280x960) / 720P(1280×720) / D1(704×576/704×480) / VGA(640×480) / CIF(352×288/352×240)
Frame Rate: Main Stream: 4K (1 ~ 25/30fps),  Sub Stream: D1/CIF(1 ~ 25/30fps)
Bit Rate Control: CBR/VBR
Bit Rate: H.264: 32Kbps~8192Kbps, H.265: 16Kbps~8192Kbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control:Auto/Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Electronic Image Stabilization(EIS): N/A
Smart IR: Support
Digital Zoom: 16x
Flip: 0°/90°/180°/270°
Mirror: Off / On
Privacy Masking: Off / On (4 Area, Rectangle)

Network
Ethernet: RJ-45 (10/100Base-T)
Protocol: HTTP; HTTPS; TCP; ARP; RTSP; RTP; RTCP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPV4/V6; QoS; UPnP; NTP; Bonjour; IEEE802.1X; Multicast; ICMP; IGMP; TLS; NFS; SSH
Interoperability: ONVIF, PSIA, CGI
Streaming Method: Unicast / Multicast
Max. User Access: 10 Users / 20 Users
Edge Storage: NAS, Local PC for instant recording, Micro SD Card 128GB
Web Viewer: IE, Chrome, Firefox, Safari
Management Software: Smart PSS, DSS, DMSS
Smart Phone: IOS, Android

Certifications
Certifications: CE (EN 60950:2000) ; UL:UL60950-1 ; FCC: FCC Part 15 Subpart B

Electrical
Power Supply: DC12V PoE (802.3af)(Class 0)
Power Consumption: <10.9W

Environmental
Operating Conditions: -30° C ~ +60° C / Less than 95% RH
Storage Conditions: -30° C ~ +60° C / Less than 95% RH
Ingress Protection: IP67, IK10

Construction
Casing: Metal
Dimensions: φ122mm×88.9mm
Net Weight: 0.49Kg
Gross Weight: 0.66Kg
