POLICEtech Q4-B5300R-Z-IRE6-A VIDEO SURVEILLANCE CAMERA

5Mp (2592×1944) - 20fps / Motorized Lens: 98°~34° / IR LED range up to 60m / Min. Illumination: 0.02 LUX / Power Consumption Max. 12W / HD/SD Video Output

  • 5 Megapixel
  • Motorizerana leča
  • Avdio vhod/izhod

:

Camera
Image Sensor: 1/2.7" CMOS
Effective Pixels: 2592(H)×1944(V), 5MP
Scanning System: Progressive
Electronic Shutter Speed: PAL: 1/25~1/100000s
Minimum Illumination: 0.02Lux/F1.8, 30IRE, 0Lux IR on
S/N Ratio: More than 65dB
IR Distance: Up to 60m (197feet)
IR On/Off Control: Auto / Manual
IR LEDs: 4

Lens
Lens Type: Motorized lens / Fixed iris
Mount Type: Board-in
Focal Length: 2.7-12mm
Max Aperture: F1.8
Angle of View: H: 98°~34°
Focus Control: Motorized
Close Focus Distance: 500mm

Video
Resolution: 5MP (2592×1944)
Frame Rate: 20fps@5MP, 25/30fps@4MP, 25/30fps@1080P
Video Output: 1-channel BNC HDCVI high definition video output / CVBS video output (Can switch)
Day/Night: Auto (ICR) / Manual
OSD Menu: Multi-language
BLC Mode: BLC / HLC / DWDR
WDR: DWDR
Gain Control: AGC
Noise Reduction: 2D
White Balance: Auto / Manual
Smart IR: Auto / Manual

Certifications
Certifications: CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface
Audio Interface: Built-in mic

Electrical
Power Supply: 12V DC ±30%
Power Consumption: Max. 12W (12V DC, IR on)

Environmental
Operating Conditions: -40°C ~ +60°C / Less than 95% RH
Storage Conditions: -40°C ~ +60°C / Less than 95% RH
Ingress Protection &Vandal Resistance: IP67

Construction
Casing: Aluminium
Dimensions: 209.9mm×90.4mm×90.4mm
Net Weight: 0.55kg
Gross Weight: 0.70kg
