> 1/2.8" 8Megapixel STARVIS™ CMOS.
> 25x optical zoom.
> Starlight technology.
> Max. 25/30fps@8M.
> IR distance up to 100 m.
> Perimeter protection.
> Face detection.
> SMD 4.0.
> IP66.

Camera
Image Sensor: 1/2.8" CMOS
Pixel: 8 MP
Max. Resolution: 3840 (H) × 2160 (V)
ROM: 4 GB
RAM: 1 GB
Electronic Shutter Speed: 1/1 s–1/30,000 s
Scanning System: Progressive
Min. Illumination: Color: 0.005 lux@F1.6; B/W: 0.0005 lux@F1.6; 0 lux@F1.6 (IR light on)
Illumination Distance: 100 m (IR)
Illuminator On/Off Control: Zoom Prio; Manual; Smart IR; Off
Illuminator Number: 4 (IR)

Lens
Focal Length: 5 mm–125 mm
Max. Aperture: F1.6–F3.6
Field of View: H: 53.1°–3.4°; V: 30.4°–1.9°; D: 59.3°–3.9°
Optical Zoom: 25×
Focus Control: Auto; semi-auto; manual
Close Focus Distance: 0.1 m–1.5 m
Iris Control: Auto; manual
DORI Distance:     Detect: 2161.4 m;Observe: 864.6 m; Recognize: 432.3 m; Identify: 216.1 m

PTZ
Pan/Tilt Range: Pan: 0° to 360° endless; Tilt: –15° to +90°, auto flip 180°
Manual Control Speed: Pan: 0.1°–200°/s; Tilt: 0.1°–120°/s
Preset Speed: Pan: 240°/s; Tilt: 200°/s
Preset:    300
Tour: 8 (up to 32 presets per tour)
Pattern: 5
Scan: 5
Power-off Memory: Yes
Idle Motion: Pattern; Preset; Scan; Tour
PTZ Protocol: DH-SD; Pelco-P/D(Auto recognition)

Intelligence
IVS (Perimeter Protection): Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification
Face Detection: Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first
Supports up to 5 face databases; registers person one by one or in batches; sets face similarity; compares faces with 10,000 faces.
SMD: SMD 4.0
Auto Patrol: It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets.

Video
Video Compression: H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+
Streaming Capability: 3 streams
Resolution: 4K (3840 × 2160); 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA(640×480);CIF (352 × 288/352 × 240)
Video Frame Rate: Main stream: 4K/4M/1080p/1.3M/720p (1–25/30 fps); Sub stream 1: D1/VGA/CIF (1–25/30 fps); Sub stream 2: 1080p/1.3M/720p/CIF (1–25/30 fps)
Bit Rate Control: CBR/VBR
Video Bit Rate: H.264: 3,328 kbps–8,192 kbps; H.265: 1,280 kbps–8,192 kbps
Day/Night: Auto (ICR)/Color/B/W
BLC: Yes
WDR: DWDR
HLC: Yes
White Balance: Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp
Gain Control: Auto; manual
Noise Reduction: 2D NR; 3D NR
Motion Detection: Yes
Region of Interest (RoI): Yes
Defog: Electronic
Digital Zoom: 16×
Image Rotation: 180°
Privacy Masking: Up to 24 areas can be set, with up to 8 areas in the same view
S/N Ratio:  ≥ 55 dB

Audio
Audio Compression: PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723

Network
Network Port: 1 × RJ-45 (10/100 Base-T)
Network Protocol: FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP
Interoperability: RTMP; CGI; SDK; ONVIF (Profile S&G&T); P2P
Streaming Method: Unicast/Multicast
User/Host: 20 (total bandwidth: 64 M)
Storage: Micro SD card (512 GB); FTP/SFTP; NAS
Browser: IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; iOS 10 and later versions
Management Software: DSS Pro; DMSS
Mobile Client: iOS; Android

Certification
CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035; CE-LVD: EN 62368-1; FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4; UL: UL62368-1

Port
Audio Input: 1 channel
Audio Output: 1 channel
Alarm Linkage: Capture; recording; send email; preset; tour; pattern; alarm digital input
Alarm Event: Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
Alarm I/O: 2/1
Audio I/O: 1/1

Power
Power Supply: 12 VDC/3A±10%; PoE (802.3at)
Power Consumption: Basic: 9.8 W; Max.: 20 W (Illuminator + alarm + PTZ)

Environment
Operating Temperature: -40 °C to +70 °C
Operating Humidity: ≤ 95%
Storage Temperature: -40 °C to +70 °C
Storage Humidity: ≤ 95%
Protection: IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection

Structure
Product Dimensions: 270.4 mm × Φ160 mm
Net Weight: 2.4 kg
Gross Weight: 3.9 kg
