System
Main Processor: Embedded processor
Operating System: Embedded Linux operating system
Network Protocol: IPv4; FTP; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP; SIP

Basic
Screen Type: Capacitive Touchscreen
Display: 7" TFT
Screen Resolution: 1024 × 600
Audio Compression: G.711a; G.711u; PCM
Audio Input: 1
Audio Output: Built-in speaker
Audio Mode: 2-way voice communication
Audio Enhancement: Echo suppression
Audio Bit Rate:    16 kHz; 16 Bit

Function
Communication Mode:Full digital
Information Release: Receive and view text information released by the management center
DND Mode: Do not disturb period can be set; Do not disturb mode
Number of Extensions: Villa: 9
Apartment: 4
Wireless Standard: IEEE802.11b/802.11g/802.11n
Wireless Frequency Range: 2.4 GHz
Performance
Casing: PC + ABS

Port
Alarm Input: 6
Alarm Output: 1
Power Output: 1 (12 V/200 mA)
Door Bell: Yes (use any alarm input port)
Network: One 10 /100 Mbps Ethernet
Network: One 10 Mbps/100 Mbps Ethernet

Alarm
SOS: Yes

General
Color: White
Power Supply: 12 VDC 1A; Standard PoE (36–57 V, 0.35 A)
Installation: Surface Mount
Certifications: CE; FCC
Accessory: Bracket and alarm ribbon cable (included)
Dimensions: 189.6 mm × 134.6 mm × 26.0 mm
Operating Temperature: –10 °C to +55 °C
Operating Humidity: 10%–95% RH (non-condensing)
Operating Altitude: Beneath 3,000 m (9,842.52 ft)
Power Consumption: Standby ≤ 2W; working ≤ 6W
Net Weight: 335 g
Gross Weight: 575 g
