Features
• Ultra-thin frame design.
• 5-inch IPS screen with a high resolution of 720 × 1280.
• 2 MP wide-angle camera with H: 119°, V: 66° and D: 142° field of view.
• Unlocks via IC cards, ID cards, Bluetooth cards, face recognition and password.
• Supports up to 20,000 users, 20,000 faces, 20,000 passwords, 100,000 IC/ID cards, 20,000 Bluetooth cards and 200,000 event records.
• Face recognition distance: 0.3–2 m.
• Face recognition accuracy: 99.9%.
• One-to-many face identification in just 0.2 seconds per face.
• Customizable user interface theme for various application scenarios.
• Provides power output for card readers and electromagnetic locks: up to 12 V / 0.5 A via PoE or 12 V / 1.5 A via external power adapter.
• IP65-rated protection (silicone sealant required for flush-mounted installation).
• TCP/IP and Wi-Fi connectivity.
• Standard PoE power supply.

System
– Main Processor: Embedded Processor
– Operating System: Embedded Linux OS
– Button Type: Mechanical
– Number of Buttons: 1
– Interoperability: ONVIF, CGI
– Network Protocols: RTSP, DNS, FTP, RTP, RTMP, SIP, SSH, HTTP, HTTPS, ONVIF

Display
– Screen Type: Capacitive Touchscreen
– Display Size: 5-inch
– Resolution: 720 × 1280

Camera
– Sensor: 1/2.8" 2 MP CMOS dual-camera system with low-light capability
– Field of View: H: 119°, V: 66°, D: 142°
– WDR: 120 dB
– Noise Reduction: 3D NR
– Video Compression: H.264, H.265
– Video Resolution:
– Main Stream: 720P, D1, WVGA, CIF
– Sub Stream: 1080P, 720P, D1, WVGA, CIF, QVGA
– Frame Rate: PAL: 25 FPS, NTSC: 30 FPS
– Bit Rate: 256 kbps–4096 kbps
– Light Compensation: Auto IR

Audio
– Audio Compression: G.711a, G.711u, PCM
– Audio Input: 1 channel
– Audio Output: Built-in speaker
– Audio Mode: Two-way audio
– Audio Enhancement: Echo suppression, digital noise reduction
– Audio Bit Rate: 16 kHz, 16 bit

Functions
– Communication Mode: Full digital
– Verification Methods: Card, Password, Face Recognition, Bluetooth
– Frequency Range: 2400–2483.5 MHz
– Max. Transmission Power (CE EIRP): ≤ 20 dBm @ 2400–2483.5 MHz
– Bluetooth: Yes
– Bluetooth Standard: BLE, BT 5.2
– Auto Snapshot: Yes
– Information Release: Supports receiving and viewing text messages from the management center
– Elevator Control: Supports elevator calling and floor access permissions
– Leave Video Messages: Yes (MicroSD card required in VTO)
– Storage: MicroSD card support up to 128 GB
– Web Configuration: Yes
– Auto Registration: Yes

RFID
– Card Type: IC Card, ID Card
– Modulation Type: ASK
– Frequency Range: IC: 13.56 MHz, ID: 125 kHz
– Max. Transmission Power: IC: 42 dBuA/m @ 10 m, ID: 66 dBuA/m @ 10 m

Network
– Max. Transmission Power: ≤ 20 dBm @ 2400–2483.5 MHz
– Wi-Fi: Yes
– Wireless Standard: IEEE 802.11b/g/n
– Wireless Frequency: 2.4 GHz

Performance
– Card Reading Distance: 0–3 cm
– Face Recognition Height Range: 1.2–2.0 m
– Face Recognition Distance: 0.3–2.0 m
– Face Recognition Accuracy: 99.9%
– Face Recognition Time: 0.2 s

Construction
– Housing Material: Tempered Glass, PC + ABS

Capacity
– Card Capacity: 100,000
– Face Capacity: 20,000
– User Capacity: 20,000

Interfaces
– RS-485: 1 channel
– Wiegand: 1 channel
– Alarm Input: 2 channels
– Alarm Output: 1 channel
– Power Output:
– Max. 12 V / 1.5 A via power adapter
– Max. 12 V / 0.5 A via PoE
– Exit Button: 1 channel
– Door Status Detection: 1 channel
– Lock Control: 1 channel (normally open)
– Network Port: 1 × 10/100 Mbps Ethernet port

Alarm
– Tamper Alarm: Yes

General
– Color: Silver
– Power Supply: Standard PoE, 12 VDC / 3 A
– Power Adapter: Optional
– Installation: Surface Mount
– Certifications: CE
– Included Accessories: Surface Mount Bracket (standard), Power Supply (optional)
– Dimensions (H × W × D): 186.8 × 81.4 × 23.3 mm
– Protection Rating: IP65 (silicone sealant required)
– Operating Temperature: –30 °C to +60 °C
– Operating Humidity: 0–90% RH (non-condensing)
– Operating Environment: Outdoor
– Operating Altitude: 0–1300 m
– Power Consumption: ≤ 8 W (standby), ≤ 10 W (operating), excluding output power
– Gross Weight: 0.82 kg
– Storage Temperature: –20 °C to +70 °C
– Storage Humidity: 30–75% RH
